Accesorios

Enclosure

The Next Generation of Robust mPOS & Enclosures

Includes:

  • Walker C2X (for MSR, dip and tap transactions)
  • Otterbox uniVERSE case connection (iPhone 6, 7, 8, regular, S and Plus models, and iPads)
  • MFi Apple Lightning connector for the iPhone / iPad connection
  • Single lightning cable charging for both iPhone and the reader

Option

  • Add Otterbox uniVERSE case to the order

In a protective cover that includes a slide connection for the Otterbox uniVERSE case system

Highlights

Take The Complexity Out Of Mobile Payment Setup

1

One charge cable; charges the iPhone & card reader simultaneously

2

Removable sled lets the user use the iPhone for personal use

3

Rugged, light, cost-efficient, multi-device interoperability

Multi-Device

For the devices of your choice:

iPhone 6, 7 & 8

(regular, S and Plus)

and iPad

Cradle

Cradle for the Walker C2X

Cradle is an indispensable addition to your Walker C2X. The cradle provides a discreet docking station for your device; there is no need to carry the device in retail venues where your mobile device remains within Bluetooth range.

Cradle Specifications

Power

5V, 500mA

Material

Plastic (ABS)

Connectivity

Micro USB

Operating Temperature

0℃ – 45℃

Swipe Speed

15cm – 100cm/sec

Operating Humidity

Maximum 95%

Certifications

RoHS, CE

Dimensions & Weight

Stand

Stand for the Nomad POS and Nomad WP2

The stand supports the new generation of mini card payment technology and MPOS devices. Standing at a height of 11.7cm with a tilt range of 140°.

  • A ratchet release mechanism and two adjustable feet hold the device securely in place.
  • Universally compatible with all small form factor retail technology, from PIN Entry Devices to smart phones.
  • Ideal solution for points of sale with limited space.
  • Fully compliant with accessibility/disability regulations
  • Presents the device for interaction
  • Protects from interference
  • All the advantages of our FlexiPole product range for security and protection of your investment
  • Maximises the lifetime of your payment device by minimising cable damage, false tampers and criminal interference
  • Drill or adhesive mounted (adhesive pad supplied)
  • No interference for WiFi, contactless, Bluetooth or NFC
  • FlexiPole products offer incredible value for money with a 50% cost saving on an average installation for a retailer
  • Available with optional lock and tether

Options

Higher Stand
Wall-Mounted

Printer

The printer features Bluetooth dual mode connectivity and a micro USB port for charging. It is fully compatible with all iOS, Android, Microsoft Windows, and Windows Phones. Simple and fast “drop-in & print” paper loading, and a detachable belt clip for versatile multimode mobility. It adds professionalism and versatility to all your mPOS transactions.

Printer Specifications

Functions

Thermal dot line printing

Resolution

8 dots/mm, 384 dots/line

Dot pitch

Horizontal: 0.125mm
Vertical: 0.125mm

Print Speed

50 mm/sec

Thermal Paper

Width: 58mm / 2.28inch
Effective printing width: 48mm
Paper roll diameter: maximum 30mm
Paper length: 6m
Sensor: no paper & cover open sensor, low battery sensor

Buttons

Bluetooth® pairing button, power on/off button & paper feeding button

Communication Interface

Bluetooth® 4.0 (classic & BLE modes), Micro USB

Power & Battery

Lithium -ion rechargeable battery 2200mAh, 3.7V

Charging

Via Micro USB, 4.5 hours for fully charged

Indicator

LED status indicator: power on, charging/low battery, Bluetooth®, error

LED Indicator

Green light On: Power on; Fully Charge
Green light Flashing: During transaction
Red light on: Battery charging
Red light Flashing: Error (No paper/Case open)
Blue light on: Bluetooth paired
Blue light flashing : Bluetooth pairing

Buzzer

Piezo buzzer

Firmware Update

Supported by over-the-air or USB, store in serial flash

Bluetooth Distance

Around 10m

Battery Life

2400(12%dots) cm Thermal paper length, or 12hrs BLE broadcasting for one fully charge

Support Operation Systems

  • Android 2.1 or above
  • iOS 6.0 or above
  • Windows Phone 8 or above
  • Microsoft Windows

Operating Temperature

0℃ – 40℃

Operating Humidity

Maximum 95%

Storage Temperature

-20℃ – 45℃

Storage Humidity

Maximum 95%

Certifications*

  • CE
  • FCC
  • RoHS

Dimensions & Weight

Contact Your Account Manager for Pricing & Availability
